M40i 403x403x95mm IP67 Stainless Steel 150kg
£743.00 (excl. VAT)
£891.60 (incl. VAT)
Available on back-order
Description
Grupo Epelsa Platform M40i/316
Plaform Size 403x403x95mm
Single cell platforms
Food industry Transport and logistics Mining industry Retail sale Agricultural and livestock Building Waste management Postal, Port and Airport Chemical and Petroleum automotive Manufacturing industry
Single cell platform in AISI-316 stainless steel
AISI-316 quality stainless steel 2-cross structure with cell support.
4 adjustable feet with a diameter of 40mm that achieve a minimum height of 117mm. and a maximum of 130mm.
Includes AISI-316 stainless steel sheath protected against corrosion and different external agents.
Incorporates IMV1 stainless steel load cell with IP67 protection and specific corrosion-resistant polishing.
2.75m cable. for connection to the viewer.
1 cell central stop and 4 in corners for overload protection.
These platforms can work under temperatures from โ10 to +40ยบC.
Net Weight: 13.65kg.
Dimensions: 403 x 403 x 95mm. (medium height)
Capacities: 15 kg, 30 kg, 60 kg and 150 kg.
Additional information
| Weight | 7.27 kg |
|---|---|
| Features/Style | IP67 |
| Machine Type | Platform |
| Power | 1 Phase (220-240v) |
| Size/Capacity | 150kg, 403x403mm |
